7 Core Black Electrical Towing Cable

7 Core Black Electrical Towing Cable
7 ''N'' Core Black Electrical Towing Cable
SKU: 6005070803
£2.24 Inc. VAT
Quantity
Usually Dispatched in1 working day

7 core electrical towing cable suitable for use in 7 pin "N" connectors for older models of caravans/trailers, which are responsible for powering the external lighting on your caravan or trailer such as the indicators, brake lights and side lights.

Please see the below table for the most up to date 12N wiring connections:

Conductor Colour Use
Yellow LH indicator
Blue Rear Fog
White Earth Return
Green RH Indicator
Brown Right Tail & Number Plate
Red Stop
Black Left Tail & Number Plate

Sold per metre, please select required length using the quantity box above.

No of Cores 7 Core
Conductor Area 6 x 1mm & 1 x 2mm
Sheathed? Yes
Sheath Colour Black
Conductor Colours Red
White
Black
Brown
Blue
Yellow
Green
Current capacity (A) - Fixing Method A N/A
Current capacity (A) - Fixing Method B N/A
Current capacity (A) - Fixing Method C N/A
Voltage Drop (mV/A/m)
Weight 0.50 kgs
